Auto Parts / 5. If the pre-cleaner consists of tubes, clean with a stiff brush,
compressed air, or water. Dry thoroughly before replacing.
6. Inspect all gaskets and replace those that are cracked, have
breaks, or are stretched out of shape. Usually, gaskets are
located in the outer cover, inner cover, filter retention washer,
filter body, dust bowl or bolts. The most frequent cause of air
filter failure is in the gaskets.
7. Reassemble, using a new or cleaned filter, in reverse order. Do not
attempt to clean or reuse the inner element that was removed. If
bolts are used on the lid, tighten uniformly using a criss-cross
pattern. Clamps and mounting bands should be checked and
uniformly tightened. Make sure the dust bowl or cup fits air tight.
8. Inspect and tighten all air induction system connections. Replace
all cracked or broken rubber connectors. Watch for unusual
amounts of dirt “trails” or dirt gathering at a connector. This
generally means an air leak.
BE ALERT FOR SIGNS OF
AIR SYSTEM LEAKAGE
A damaged or leaky air induction ■ Watch all connections for
system can rapidly affect the life tightness along with housing
of an engine. Thorough, periodic and air induction tubes for
inspections will prevent costly fractures.
problems.
■ Inspect sealing surfaces for
■ A damaged element may
warpage or dents that can
have areas of concentrated
cause air leakage. Replace
dust on the clean side of the
questionable parts.
element.
■ A gasket leak may show up ■ Check restriction gauge
in the form of dust patterns fittings and vacuum lines to
near the seals. make sure they are tight.
